Characteristic

Information

Maximum input voltage

DC + peak AC1

1.5 kV to 20 kV. See frequency derating curve in Figure 1--4. (DC plus peak AC rating is limited to temperatures below 35℃.)

Peak pulse

40 kVa (Never exceed 20 kV rms)
Duty cycle derating -- 100 ms maximum duration at 10% maximum duty cycle. See duration and duty cycle derating curve in Figure 1--5.
Altitude derating -- Peak pulse derated linearly from 40 kV at 8000 feet (2440 m) to 30 kV at 15,000 feet (4570 m) altitude.
Relative Humidity (RH) derating -- Voltage derated with increasing temperature and relative humidity.

Bandwidth (--3 dB)

Test conditions: Test oscilloscope bandwidth must be ≥100 MHz, Zsource = 25 Ω

10-ft cable

75 MHz

25-ft cable

25 MHz

Rise Time2

10-ft cable

≤4.67 ns (calculated from bandwidth)

25-ft cable

≤14 ns (calculated from bandwidth)

DC attenuation

1000:1 ±3% (Excluding oscilloscope error)
Test conditions: Oscilloscope input resistance must be 1 MΩ ±2%

Temperature

-55C to +75C (--67F to +167F)

Operating

DC + peak AC

0C to +35C (+32F to +95F)

Peak Pulse

0C to +50C (+32F to +122F)

Humidity

Nonoperating / Operating

95% relative humidity at +50 °C (+122 °F)

Maximum altitude

Nonoperating

15,000 m (50,000 ft)

Operating

4,600 m (15,000 ft)

Vibration (random)

Nonoperating

3.48 g rms from 5 to 500 Hz. Ten minutes on each axis.

Operating

2.66 g rms from 5 to 500 Hz. Ten minutes on each axis.

Shock (nonoperating)

500 g, half sine, 0.5 ms duration, 18 shocks total in three axis.

Time Limitations

Less than 70% of Rated Input Voltage at 0--35 C

No time limit

Greater than 70% of Rated Input Voltage at 0--35℃

30 minutes maximum in any 2.5 hour period

35--50℃

15 minutes maximum in any 2.5 hour period
