Locking

screw connection

Protection

IP 50 to IP 54 with conexil in the housing, flat-gasket for panel connector and cable connector seal

Contacts

3 to 52 contacts ? 2 mm – ? 3 mm – ? 4 mm non-removable solder contacts

Max. current

15 A ? 2 mm – 35 A ? 3 mm – 50 A ? 4 mm

Contact resistance between pin and socket

< 0,0015Ω ? 2 mm – < 0,0010Ω ? 3 mm – < 0,0007Ω ? 4 mm

Breakdown voltage between adjacent contacts

> 2500 Volts (RMS)

Breakdown voltage between peripheral contacts and ground

> 1500 Volts (RMS), (> 2000 Volts (RMS) 4 contacts ? 4 mm)

Insulation resistance

> 5000 MΩ

Operating temperature

-40 °C to +100 °C (500 hours at +125 °C)

Materials

Nickel-plated light alloy, silver-plated brass contact, PBT insert except contacts diameter 4 mm which are gold-plated brass

Max. cross-section of soldered conductors

1,34 mm2 ? 2 mm – 3,18 mm2 ? 3 mm – 5,26 mm2 ? 4 mm
