KOYO ELECTRONICS模擬電流輸入模塊F2-08AD-1產品參數
Technical Attributes | |
Brand | DirectLOGIC |
Item | Input module |
I/O Module Type | KOYO ELECTRONICS |
Series | DL205 |
Number Of Input Channels | 8 |
Input Signal Type(s) | Current |
KOYO ELECTRONICS Input Type | Sinking |
Isolated Channels | No |
Number of Non-Isolated Input Commons | 1 |
Input Resolution | 12-bit |
Input Current Signal Range | 4-20 mA |
External Power Requirement | 24 VDC |
Programming Software | DirectSOFT programming software v4.0 or later |
KOYO ELECTRONICS模擬電流輸入模塊F2-08AD-1產品介紹
必須至少有一個外部電源才能與F2-08AD-1 8通道模擬電流輸入模塊一起使用。不需要為模塊電源和電流變送器電源使用相同的電源。可以使用單獨的電源。
F2-08AD-1 8通道模擬電流輸入模塊包含重要的硬件功能。
模擬輸入與PLC邏輯光學隔離。
為了提高可用性和便攜性，接線端子可輕松拆卸，以確保無需斷開接線即可輕松拆卸F2-08AD-1 8通道模擬電流輸入模塊。
如果使用DL240，DL250-1或DL260 CPU，則可以一次掃描讀取所有通道。
F2-08AD-1 8通道模擬電流輸入模塊的功率預算要求為110mA（* 60mA最大值，5VDC（由底座提供）。環境空氣要求是不允許有腐蝕性氣體。工作溫度為0-60°） C（32-140°F）。相對濕度5–95％（無冷凝）。
F2-08AD-1 8通道模擬電流輸入模塊是8通道模擬輸入電壓模塊。輸入范圍是0-5 VDC和0-10 VDC。通道數為8，單端（一個公共）。分辨率為12位（4096中為1英寸）單極性（0–4096）13位（1 in 8192）為雙極性（-4095 – +4095）。PLC更新速率是每次掃描最大1通道（DL230 CPU），每次掃描最大8通道（DL240 / 250-1 / 260 CPU）。輸入點要求是12個二進制數據位，3個通道ID位，1個損壞的變送器檢測位，16點（X）輸入模塊。
F2-08AD-1可以安裝在DL230的任何插槽中。但是，要考慮的一個問題是，如果放置模塊以使輸入點不在V存儲器邊界上開始，則指令無法訪問數據。
You must have at least one external power supply for use with the F2-08AD-1, 8-Channel KOYO ELECTRONICS Current Input Module. It is not required that the same power sources be used for the module supply and the current transmitter supply. Separate power supplies can be used instead.
The F2-08AD-1, 8-Channel KOYO ELECTRONICS Current Input Module contains valuable hardware features.
The KOYO ELECTRONICS inputs are optically isolated from the PLC logic.
For improved usability and portability, the terminal block is easily removable to ensure the F2-08AD-1, 8-Channel KOYO ELECTRONICS Current Input Module is easily removable without disconnecting wiring.
If a DL240, or DL250-1, or DL260 CPU is used, all channels can be read in one scan.
The power budget requirement for the F2-08AD-1, 8-Channel KOYO ELECTRONICS Current Input Module is 110mA (*60mA maximum, 5VDC (supplied by base). The environmental air requirement is no corrosive gases permitted. The operating temperature 0-60°C (32-140°F). The relative humidity 5–95% (non-condensing).
The F2-08AD-1, 8-Channel KOYO ELECTRONICS Current Input Module is a 8-Channel KOYO ELECTRONICS input voltage module. The input range is 0-5 VDC and 0-10 VDC. The number of channels is 8, single ended (one common). The resolution is 12 bit (1 in 4096) unipolar (0–4096) 13 bit (1 in 8192) bipolar (-4095 – +4095). The PLC update rate is 1 channel per scan maximum (DL230 CPU) 8 channels per scan maximum (DL240/250-1/260 CPU). The input points requirement is 12 binary data bits, 3 channel ID bits, 1 broken transmitter detection bit, 16 point (X) input module.
The F2-08AD-1 can be installed in any slot in a DL230. However, one consideration is that if the module is placed so the input points do not start on a V-memory boundary, the instructions cannot access the data.
KOYO ELECTRONICS模擬電流輸入模塊F2-08AD-1其他常見型號：
KOYO ELECTRONICS F2-04AD-1
KOYO ELECTRONICS F2-04AD-2
KOYO ELECTRONICS F2-08AD-1
KOYO ELECTRONICS F2-08AD-2
KOYO ELECTRONICS F2-02DA-1
KOYO ELECTRONICS F2-02DA-2
KOYO ELECTRONICS F2-02DAS-1
KOYO ELECTRONICS F2-02DAS-2
KOYO ELECTRONICS F2-08DA-1
KOYO ELECTRONICS F2-08DA-2
KOYO ELECTRONICS KOYO ELECTRONICS input module NEW + ORIGINAL+ ONE YEAR WARRANTY
