KEYSIGHT采樣模塊DAQM909A技術參數
Measurement functionality | |
DC Volt | |
ADC per channel | 800 kSals @ 24-bit |
Range (Hi, Lo Input to Earth)' | 0.3 Vpk, 1 Vpk, 3 Vpk, 18 Vpk |
Range (iferential input) | 0.6 Vpk, 2 Vpk, 6 Vpk, 36 Vpk |
Range (iferential input - sinewave Vrms)2 | 0.42 Vrms, 1.4 Vrms. 4.2 Vmms, 25 Vrms |
Residual noise (20 Hz - 20 kHz) | 7 μV/mms, 16 μVms, 52 uV/rms, 175 μVrms |
IEPE current source | OFF or ON, ON (2mA - 4mA) |
IEPE currents source compliance vltage | 20 V |
Trigger count | 1 to 85k |
Sample count | 1 to 16M |
Pre-trigger count | 0 to sample count |
Trigger amm event (System) | IMM, Scan-sweep, Alarm-# |
Trigger event (channel) | Software, IMM, Level/Slope |
Trigger event (same module) | ExternalSlope, Chan-# |
Trigger event (module-module) | Any Chan# |
Extemal trigger input (one per module) | TTL compatible |
Extemal trigger delay | 0- 1000s, 1 us steps |
Extemal tigger latency | 1-sample |
Extemal Trigger-In terminals | Screw terminal (2 20-gage wire) |
Measurement input terminals | Screw terminal (2 20-gage wire) |
Frequency or Time domain anti-alas fiters | Yes |
Time-stamped measurements | Yes (Acoustic Start) |
Acquisition memory/channel | 16M to 48M Samples |
Log multiple digtied records (volate) | Yes |
Automalic file copy to flash drive | Yes |
KEYSIGHT采樣模塊DAQM909A產品介紹
4通道同時采樣，采用差分輸入
頻域采樣率高達100 kSa/s，時域采樣率高達800 kSa/s，具備24位分辨率
差分輸入范圍可選擇，最高達36 Vpk
IEPE電流源（2mA - 4mA）
每通道采集內存，16 MSa至48 MSa
Keysight DAQM909A模塊使DAQ970A和DAQ973A數據采集系統能夠執行動態數據采集，適用于諧波和噪聲失真、功率分析以及機電設備的聲學特性分析等應用。
每個通道可以獨立編程為四種輸入模式之一和電流源設置。三個這樣的模塊組合在一個機框中可以提供12通道的同步數字化。
標準產品包括：
1個DAQM909A，4通道同時采樣模塊
1份功能測試證書
4 Channel simultaneous sampling with differential inputs
Sample rates of up to 100 kSa/s (in frequency domain) and up to 800 kSa/s (in time domain) with 24-bit resolution
Differential input range selectable up to 36 Vpk
IEPE current source (2mA - 4mA)
Acquisition memory/channel, 16 MSa to 48 MSa
The Keysight DAQM909A module enables the DAQ970A and DAQ973A Data Acquisition System to perform dynamic data acquisition for applications such as harmonic and noise distortion, power analysis, and acoustic characterization of electromechanical devices.
Each channel can be independently programmed to one of four input modes, and current source settings. Three of these modules put together in a single mainframe can provide 12 channels of simultaneous digitization.
Standard Product Includes:
1 DAQM909A, 4 Channel Simultaneous Sampling Module
1 Functional Test Certificate
