BER-MAR電機AF.71.S4.5000技術規格
Electrical data | |
Rated Power | 0.37 kW |
RPM | 1380 min-1 50Hz |
Frequency | 50/60 Hz |
Poles | 4 |
Power Supply(+/-10%) | 230 VD/50Hz |
Rated Torque | 2.58 Nm |
Rated Current | 1.95/1.13 A (In) |
Starting Current | 4.3 x In (A) |
Starting Torque | 2.5 xCn (Nm) |
Torque MAx. | 2.4 xCn (Nm) |
Efficiency Class | IE1 |
Power Factor cosf | 0.75 100% Efficiency |
General data | |
Frame Size | 71 |
Mounting | B5 |
Weight | 7.7 Kg |
Casing Material | ALUMINUM |
Protection | IP 55 |
Tropicalization | ON REQUEST |
Vibration Class | N |
Duty | S3 70% |
Direction of rotation | BIDIRECTIONAL |
Cooling System | IC 411 |
Cable Entry | 2 M16x1.5 - 1 M20x1.5 |
Standards | IEC/DIN/ISO/VDE/EN |
Execute at Standard | IEC 60034-1 |
Paintwork | Standard: Aluminum |
Year of construction | Reference on the motor plate |
Site conditions | |
Ambient Temperature | from -20°C to +40°C |
Altitude above sea level | 1000 m |
BER-MAR電機AF.71.S4.5000技術尺寸
BER-MAR電機AF系列其他常用型號：
BER-MAR AF.71.S4.5000
BER-MAR AF.71.S4.5050
BER-MAR AF2 802-4-B3
BER-MAR AF 713-2-B3
BER-MAR AF2 90S-6-B3
BER-MAR AF3 90S-6-B3
BER-MAR AF 100L1-8-B14
BER-MAR AF3 801-2-B5
BER-MAR AF 713-4-B3
BER-MAR AF2 100L1-2-B3
BER-MAR motor NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業集產品開發、設計、制造、銷售、于一體，代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于BER-MAR電機AF.71.S4.5000的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for BER-MAR products, please feel free to dial 0086-21-3100 6702/ send request email to sales@wap.pnxqid.cn / browse our website: www.wap.pnxqid.cn.
BER-MAR電機AF.71.S4.5000技術參數及尺寸
