SUN線圈770224技術參數
Technical Data | |
Maximum Coil Temperature at 68oF (20oC) Ambient | 218oF (105oC) |
Arc Suppression (TVS) | Included |
Power Consumption (cold) - at rated voltage | 22 watts |
Maximum Ambient Temperature | 122 °F |
Voltage/Frequency | 24 VDC |
Operating Voltage Range | +/- 10% nominal |
Duty Cycle Rating | 1 |
Connector | ISO4400 - EN/DIN175301-803, Form A (ISO/DIN 43650) 3-pin |
Connector Environment Rating | IP65/IP67 |
Solenoid Tube Diameter | .75 in. |
Coil Nut Torque | 4.5 lbf in. |
Model Weight | 0.51 lb. |
SUN線圈770224產品介紹
? 線圈繞組采用 N 級（額定溫度為 392° F [200 °C]）磁線。
? 直流線圈內置 TVS 浪涌抑制二極管。標稱擊穿電壓：68V。型號代碼 1.5 KE68CA 75°C 時的穩態功率耗散為 6.5 W，峰值脈沖耗散為 1500 W（持續 1 毫秒），非重復性。
? 需要帶有配套連接器的電源線，但不包含在產品中。
? 線圈具有磁對稱性，可以以任意方向安裝在電磁管上，而不會影響性能。
? 為了獲得最佳比例性能，應使用具有電流感應和可調抖動功能的放大器。抖動應在 100 - 250 Hz 之間可調。
? 此線圈符合 CE 標準。它符合低壓指令 (2006/95/EC) 和 EN 60204-1:2006 的要求。
? IP 等級取決于所使用的線圈連接器和配套連接器。
? 符合 RoHS 標準。限制材料重量總量低于 0.1%。
? 外部鋼殼鍍有透明三價鋅。
? Coil windings utilize Class N, (392° F [200 °C] rated) magnet wire.
? A TVS surge suppression diode is built into DC coils. Nominal breakdown voltage: 68V. Model code 1.5 KE68CA Steady state power dissipation @ 75°C is 6.5 W and peak pulse dissipation is 1500 W for 1 ms, nonrepetitive.
? Power cable with mating connector is required and is not included with product.
? The coil is magnetically symmetrical and can be mounted in either direction on the solenoid tube without affecting performance.
? For optimum proportional performance, an amplifier with current sensing and adjustable dither should be used. Dither should be adjustable between 100 - 250 Hz.
? This coil is CE compliant. It meets the requirements of the Low Voltage Directive (2006/95/EC) and EN 60204-1:2006.
? IP rating is dependent on the coil connector and the mating connector used.
? RoHS compliant. Restricted materials less than 0.1% total by weight.
? The external steel shell is plated with clear zinc trivalent.
