HYDAC壓力傳感器HDA 8400系列描述
The pressure transducer series HDA 8400 was specially developed for series utilisation, e.g. in mobile applications. As is the case with most of our pressure transducer series, the HDA 8400 is based on a robust, long-life thin-film sensor.
All of the parts which come into contact with media (sensor and pressure connection) are made of stainless steel and are welded together with one another. This means that there are no sealing points in the interior of the sensor. The possibility of leakage is excluded.
The pressure transducers are available in various pressure ranges from 0 ... 40 bar to 0 ... 600 bar. Commercially available analogue output signals are available for integration in modern control systems, e.g. 4 ... 20mA, 0 ... 5V, 1 ... 6V or 0 ... 10 V. Ratiometric output signals are also obtainable.
Different connection plugs integrated in the device are available for the electrical connection.
A basic accuracy von ±0.5% FS typ., combined with a low temperature drift, opens up a wide range of applications for the HDA 8400.
Accuracy ±0.5% FS type.
Measurement ranges: between 0 .. 40 bar and 0 .. 600 bar
Outstanding data with respect to temperature influence and EMC
Small, compact Very compact design
HDA 8400 系列壓力傳感器專為系列應用而開發，例如在移動應用程序中。與大多數壓力傳感器系列一樣，HDA 8400 基于堅固耐用的薄膜傳感器。
所有與介質接觸的部件（傳感器和壓力連接）均由不銹鋼制成，并相互焊接在一起。這意味著傳感器內部沒有密封點。排除泄漏的可能性。
壓力傳感器可用于從 0 ... 40 bar 到 0 ... 600 bar 的各種壓力范圍。市售模擬輸出信號可用于集成到現代控制系統中，例如4 ... 20mA、0 ... 5V、1 ... 6V 或 0 ... 10 V。還可以獲得比例輸出信號。
集成在設備中的不同連接插頭可用于電氣連接。
±0.5% FS 典型值的基本精度與低溫漂移相結合，為 HDA 8400 開辟了廣泛的應用范圍。
精度 ±0.5% FS 型
測量范圍：0 .. 40 bar 和 0 .. 600 bar 之間
關于溫度影響和 EMC 的出色數據
小巧緊湊 非常緊湊的設計
HYDAC壓力傳感器HDA 8400系列其他常用型號：
HYDAC HDA 8446-A-0250-000
HYDAC Temperature Sensor NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于HYDAC壓力傳感器HDA 8446-A-0250-000的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for HYDAC products, please feel free to dial 0086-21-3100 6702/ send request email to sales@wap.pnxqid.cn / browse our website: www.wap.pnxqid.cn.
HYDAC壓力傳感器HDA 8400系列HDA 8446-A-0250-000規格描述
