AII氧傳感器GPR-11-60-4技術參數
Oxygen Sensor Model | GPR-11-60-4 |
Measuring Range | 0-100% O2 |
Signal Output | 35-55 μA |
Response Time 90% | 9 Seconds |
Accuracy Full Scale | 1% |
Accuracy FS Over Operating Range | 5% |
Drift % Signal Month | < 1% |
Linearity | 1% |
Humidity Non-Condensing | 0-99% RH |
Temperature Coefficient | 2.54% |
Operating Temperature | 0-45° C |
Operating Pressure | Constant 5-30 PSIG |
Flow Rate | .1-10 LPM |
Expected Life | 60 Months |
Storage | 0-40° C |
Electrical Connections | 4 Pin Male Conn. 1/4" NPT |
Recommended Storage | < 6 months |
AII氧傳感器其他常用型號：
AII GPR-11-32-RT
AII GPR-11-60-RTS
AII XLT-11-24-R
AII XLT-11-24-RTS
AII GPR-11-60-4
AII GPR-11-32-4
AII OXYGEN SENSOR NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于AII氧傳感器GPR-11-60-4的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for AII products, please feel free to dial 0086-21-3100 6702/ send request email to sales@wap.pnxqid.cn / browse our website:www.wap.pnxqid.cn.
