HONEYWELL傳感器C7150B1004/U規格描述
Product Specifications | |
Application | Temperature Mixed Air Sensor for Duct mixed or discharge air |
Dimensions (in.) | 2 in. high, 2 1/2 in. wide, 3/4 in. deep |
Dimensions (mm) | 51 mm high x 64 mm wide x 19 mm deep |
Used With | W973 and M7415; W7210, W7212, W7213, W7214, W7215, W7459, W7460 |
Item Type | Product |
Mounting | Mount on a mounting bracket (not included) inside the mixed air or discharge air duct. |
Approvals, Underwriters Laboratories Inc. | Component Recognized |
Electrical Connections | 1/4 in. (6 mm) quick-connect terminals. |
Sensor | 3000 ohms @ 25C NTC |
Operating Temperature Range (F) | 40 F to 110 F |
Operating Temperature Range (C) | 4 C to 43 C |
Approvals, CE | Report: GV97-011 |
Color | Black |
Ambient Temperature Range (F) | 250 F Maximum |
Ambient Temperature Range (C) | 121 C Maximum |
HONEYWELL傳感器C7150B1004/U產品介紹
C7150 Solid State mixed air sensor is used with Honeywell economizer logic modules and W973 and M7415 to proportion outdoor and return air dampers in economizer systems.
Features
Uses thermistor sensing element in ventilation duct systems.
Negative temperature coefficient (NTC) causes resistance to decrease as sampled air temperature increases.
Resistance change used as in input to control W973 and M7415.
Requires no settings or calibration.
Mounts on duct surface with four screws (not supplied).
C7150固態混合空氣傳感器與霍尼韋爾（中國）節能器邏輯模塊以及W973和M7415配合使用，可在節能器系統中按比例分配室外和回風閥。
特征
在通風管道系統中使用熱敏電阻傳感元件。
負溫度系數（NTC）導致電阻隨著采樣空氣溫度的升高而降低。
電阻變化用作控制W973和M7415的輸入。
無需設置或校準。
用四顆螺釘（未提供）安裝在管道表面上。
HONEYWELL傳感器C7150系列其他型號：
HONEYWELL C7150B1004
HONEYWELL C7150B1004/U
HONEYWELL C7250A1001/U
HONEYWELL carbon monoxide sensor NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業集產品開發、設計、制造、銷售、服務于一體，代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于HONEYWELL傳感器C7150B1004/U的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for HONEYWELL products, please feel free to dial 0086-21-3100 6702/ send request email to sales@wap.pnxqid.cn / browse our website: www.wap.pnxqid.cn.
HONEYWELL傳感器C7150B1004/U技術數據
