TELCO傳感器LT-110L-AP38-15產品參數
Specification | |
Product Data | |
Function | Transmitter |
Housing Material | Plastic |
Housing | ?10 |
Connection | 15 m cable |
Sensing Range | Up to 40 m |
Optical Angle | +/- 5° (emission) |
Indicators | Yes |
Technical Data | |
Photo Transistor | - |
Power On Indicator | - |
Output Indicator | Yellow LED |
Light Source | Infrared |
Cable | 2 x 0,25 mm2 |
Housing Material Sensor Housing | Polycarbonate |
Housing Material Lens Cover | Polycarbonate |
Transmitter Diode | Ga Al As, (880 nm) |
Cable Sleeve | PVC ? 4,0 mm |
Min. Cable Bending Radius | 45 mm |
Environmental Data | |
Vibration | 10 – 55 Hz, 0,5 mm |
Shock | 30 g |
Operation Temperature | – 25 to +65 °C |
Storage Temperature | – 40 to +80 °C |
Sealing Class | IP 67 |
Light Immunity 20? | > 100 000 lux |
TELCO傳感器LT-110L-AP38-15產品介紹
遠程傳感器系列由發射器LT和接收器LR組成，可與PA，MPA或PAB程序中的Telco光電放大器配合使用。
遠程傳感器可通過電纜或插頭連接在各種外殼中使用，并且可以在直通光束或漫射接近模式下使用。
該系列可提供可選的電源（LR）和輸出（LT）監視器LED，用于任何集成了傳感器LED驅動功能的Telco光電放大器。
The remote sensor series, which consists of a transmitter LT and receiver LR, is made to operate in conjunction with a Telco photoelectric amplifier from the PA, MPA or PAB programmes.
The remote sensors are available in a wide range of housings, with either cable or plug connection, and may be used in thru-beam or diffuse proximity mode.
The series is available with optional power-(LR) and output-(LT) monitor LEDs for use with any Telco photoelectric amplifier which has the sensor LED drive feature incorporated.
TELCO傳感器LT系列其他常見型號：
TELCO LT100AP38T3
TELCO LT100S3015
TELCO LT100S305
TELCO LT100SG15
TELCO LT100SG5
TELCO LT100SGT3
TELCO LT100TB3815
TELCO LT100TB385
TELCO LT100TB38T3
TELCO LT100TB58J
TELCO LT100TP3815
TELCO LT100TP385
TELCO Sensors NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于TELCO傳感器LT-110L-AP38-15的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for TELCO products, please feel free to dial 0086-21-3100 6702/ send request email to sales@wap.pnxqid.cn / browse our website: www.wap.pnxqid.cn.
