ESIT稱重傳感器HSC-V系列技術參數
Specifications; | ||||
Maximum capacities (Emax) | kg | 4,000,060,000,100,000 | ||
Accuracy (OIML R60) | C1 | C3 | C4 | |
Maximum number of verification intervals () | 1000 | 3000 | 4000 | |
Minimum verification interval () | Emax/3500 | Emax/6750 | Emax/20000 | |
Combined error | % | ≤ ±0.05 | ≤ ±0.02 | ≤ ±0.015 |
Creep error over 30 min. (DR) | %Emax | 0.0039 | 0.003 | |
Minimum load | %Emax | 0 | ||
Maximum safe overload | %Emax | 150 | ||
Maximum safe sideload | %Emax | 100 | ||
Ultimate load | %Emax | 300 | ||
Stretching (Emax) | mm | ≤ 0.3 | ||
Maximum excitation voltage (Umax) | V | 15 | ||
Rated output (Cn) | mV/V | 2 ±0.1% | ||
Zero balance | %Cn | ≤ ±1.0 | ||
Input Resistance | Ω | 385±20 | ||
Output Resistance | Ω | 351 ±3 | ||
Insulation resistance | MΩ | ≥500 | ||
Compensated temperature range | °C | -10...+40 | ||
Operating temperature range | °C | -40...+80 | ||
Load cell material | Steel | |||
Sealing (EN60529) | IP68 | |||
Cable length | m | 13 | ||
Cable diameter | mm | 8 | ||
Weight | kg | 12.6 | ||
Package dimensions / weight | cm/kg | 34 x 25 x 23 / 15.3 | ||
ESIT稱重傳感器HSC-V系列介紹
說明
HSC-V 剪切梁式傳感器專為在工業環境中的大容量壓縮型電子重量和力測量應用而開發。精確且堅固的 HSC-V 傳感器提供了對側向力和過載條件的高抵抗力。
HSC-V 傳感器適用于惡劣工業條件，廣泛應用于大容量汽車衡、鐵路衡、罐體稱重系統以及過程稱重應用。其采用涂有防腐蝕涂料的鋼合金結構，且應變計區域焊接有不銹鋼蓋，符合 IP68 標準，表明其可完全浸入水中。
特點
符合 OIML R60 標準認證
抗側向力
重載設計
密封應變計區域
薄型機身
IP68 工業防護
Explanation
The HSC-V shear beam load cell has been developed for use in high capacity, compression type electronic weight and force measurement applications in industrial environments. The precise and rugged HSC-V load cell offers high resistance to side forces and overload conditions.
The HSC-V load cells are suitable for severe industrial conditions and they find application in high capacity vehicle scales, railway scales, tank weighing systems and process weighing applications. With its steel alloy construction coated with corrosion-retardant paint as well as its strain gauge area welded with a stainless steel cover, HSC-V is protected to IP68 standards suggesting that they are fully immersible.
Features
Certified to OIML R60 standards
Resistant to side forces
Heavy duty
Hermetic-sealed strain gauge area
Thin profile body
IP68 industrial protection
ESIT稱重傳感器HSC-V系列其他常用型號：
ESIT HSC 60T V C3 10338
ESIT HSC-V 40
ESIT HSC-V 20
ESIT HSC-V 100
