GOTTING傳感器HG G-19600ZA技術參數
Technical Data Magnet Sensor | |
Nominal reading height | 60 mm when using the magnetic tape HW MAT00003 |
Casing dimensions | 156 x 31 x 53 mm (W x D x H) |
Casing material | Polycarbonate |
Weight | 150 g |
Protection class | IP 54 |
Relative humidity at 25° C | 95% (without condensation) |
Operating temperature range | -20° C to +50° C |
Storage temperature range | -20° C to +70° C |
Supply voltage | + 24VDC |
Current consumption | < 100 mA |
Connector | 2 Stecker M12 (1x 5 pol. / 1x 8 pol.) |
Analog outputs | – AOUT 1 (X): -10 to +10 VDC |
Digital output | Detect: +24 VDC (+Ub), max. 20 mA |
Serial interface | RS232 |
GOTTING傳感器HG G-19600ZA產品介紹
? 室內/IP 54
? 數字磁力計技術，堅固耐用且免維護
? 對于軸向偏振磁帶（寬度 50 毫米），讀取距離 60 毫米
? 磁力帶易于安裝
? 檢測磁帶不受磁道污垢的影響
? 通過 5 個 LED 顯示系統狀態
? 三個獨立的檢測系統，用于識別岔路
? 可以通過數字輸入選擇賽道的岔道
? 模擬輸出：磁通密度Z (0 ... 10 VDC)、磁通密度X (-10 ... +10 VDC)
? 數字輸出：檢測讀取區域中的磁帶（+24 VDC，最大 20 mA）
? 避免強磁場靠近傳感器
? Indoor / IP 54
? Digital magnetometer technology, robust and maintenance free
? For axially polarized magnetic tape (widths 50 mm), reading distance 60 mm
? Magnetic band easy to install
? Detection of the magnetic tape not influenced by dirt on the track
? Display of the system status via 5 LEDs
? Three independent detection systems for the recognition of turnoffs
? Turnoffs in the track can be selected via digital inputs
? Analog outputs: Flux density Z (0 ... 10 VDC), flux density X (-10 ... +10 VDC)
? Digital output: Detection of a magnetic tape in the reading area (+24 VDC, max. 20 mA)
? Avoid strong magnetic fields close to the sensor
GOTTING傳感器HG系列其他常用型號：
GOTTING HG G-19380-B
GOTTING HG G-19370-B
GOTTING HG G-19603ZA
GOTTING HG G-19600ZA
GOTTING Magnet Sensor NEW + ORIGINAL+ ONE YEAR WARRANTY
