美國METROLOGIC激光功率計45-545產品介紹及特征

45-545A型數字激光功率計是一款多功能儀器，具有許多研究應用和CDRH符合性測量所需的準確度。本機具有標準和峰值/保持輻射測量的設置以及用于校準/測量用戶定義標準的百分比模式。該儀表采用帶有大號12毫米高數字的低功耗LCD。

在標準和峰值/保持輻射模式下，儀表的四個量程顯示19.99μW，199.9μW，1.999 mW和19.99 mW的滿量程讀數。

檢測頭是黑色陽極氧化鋁，耐用，直徑25毫米，深度30毫米。0.5米的可伸縮屏蔽電纜將探頭與儀表內部電子元件電連接。側面底盤上的卡扣式安裝可在不使用時固定頭部?？拐鸢惭b座中的光學傳感器和濾波器位于頭部內部。

BNC輸出端子可提供與檢測器光功率成比例的模擬信號。它可用于驅動帶狀記錄儀，示波器和其他設備。模擬量輸出范圍從0到+2伏。光檢測器和內部電路可檢測并放大高達100 kHz的信號。（這使得儀表可以在教育演示中解調來自激光器的音頻信號。）

在強度穩定的635nm二極管激光下，校準在滿量程的5％以內。對于波長在500到950 nm之間的其他波長的單色光，內置的輻射過濾器可以校正到標準的20％以內。手冊中的圖表列出了450至950 nm的標稱響應。

功率計封裝在20×914×9厘米的外殼內，工作溫度范圍為10-30°C

特征：

易于閱讀的數字讀數

零點偏移調整來補償環境光線

在100％的偏移量控制中有輻射模式; 以百分比直接顯示讀數

可拆卸探測器頭帶螺紋安裝孔，可用于環臺或光學工作臺

包括校準圖表和指導指南

雙電源（110 VAC或兩個9V電池便于攜帶）

The model 45-545A digital laser power meter is a multi-purpose instrument with the degree of accuracy required for many research applications and CDRH compliance measurements. This unit features settings for standard and peak/hold radiometric measurements and percentage mode for calibrating/measuring to user-defined standards. The meter employs a low-power LCD with large, 12 mm-high numerals.

In standard and peak/hold radiometric modes, the meter's four ranges display full-scale readings of 19.99 μW, 199.9 μW, 1.999 mW and 19.99 mW.

The detector head is black anodized aluminum for durability, 25 mm in diameter and 30 mm in depth. A 0.5 m retractable, shielded cable electrically connects the detector head to the meter's internal electronics. A snap-mount on the side chassis secures the head when not in use. Optical sensor and filters in shock-resistant mounts are located inside the head.

An analog signal, proportional to the optical power on the detector, is available from a BNC output terminal. It may be used to drive strip charge recorders, oscilloscopes and other devices. Analog output ranges from 0 to +2 volts. Signals up to 100 kHz can be detected and amplified by the optical detector and internal circuitry. (This allows the meter to demodulate audio signals from lasers in educational demonstrations.)

Calibration is within 5 percent of full scale at intensity stabilized 635nm diode laser light. For monochromatic light of other wavelengths within 500 to 950 nm, a built-in radiometric filter corrects to within 20 percent of standard. A chart in the manual lists nominal response from 450 to 950 nm.

The power meter is enclosed in a 20 x 914 x 9 cm housing and has an operating range from 10-30°C.
